DR15S-M30E-2UPN8X2-H1141 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Radar Sensor
DR15S-M30E-2UPN8X2-H1141
Order ID no. 100030149
In Stock
List Price
€604.00
home
Home
Loading...
Technical Data
Protection class
IP67, IP69K
Switching element function
NO/NC programmable
Output function
PNP/NPN
Design
Threaded barrel
Detection type
contactless
Communication protocol
IO-Link
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless steel
Housing quality
1.4401 (AISI 316), PTFE
Ambient temperature min. (°C)
-25
Ambient temperature max. (°C)
65
Max. range (mm)
15000
Beam angle
15°
Measuring principle
Radar
Function
Radar scanner
Operating voltage
DC
Construction size
M30 x 1.5
Key Features
Electrical connection
Connector
Output function
PNP/NPN
Beam angle
15°
Max. range (mm)
15000
Item Total
€604.00
