Temperature Detection
TP-206A-CF-H1141-L300
Order ID no. 9910478
In Stock
Price Group
D2
List Price
€64.40
home
Turck-Shop
Sensors
Temperature Sensors
TP-206A-CF-H1141-L300
Technical Data
Protection class
IP67
Approvals
cULus
Design
Temperature probe
Process connection
For compression fittings, thermowell or direct mounting
Immersion depth L (mm)
300
Detection type
medium contact
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
120
Mounting conditions
Immersion sensor
Measuring range
-50…500 °C
Electrical output
Resistance
Key Features
Electrical output
Resistance
Process connection
For compression fittings, thermowell or direct mounting
Measuring range
-50…500 °C
